TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T

Certification
China Shenzhen Gigaopto Technology Co., Ltd. certification
China Shenzhen Gigaopto Technology Co., Ltd. certification
I'm Online Chat Now

TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T

TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T
TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T

Large Image :  TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T

Product Details:
Place of Origin: China
Brand Name: Generic
Certification: CE, FCC, ROHS, ISO9001, ISO14000, MSDS, REACH, CP65, TUV, UL
Model Number: HUAWEI MA5608T GPON SFP
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: negotiable
Packaging Details: Single Package,10 or 20pcs per Tray,30 or 50 or 100pcs per box, 400 or 600pcs per carton
Delivery Time: 1-5 work days
Payment Terms: T/T, L/C
Supply Ability: 50,000pcs/month

TX1490nm / RX1310nm GPON OLT C+ SFP Transceiver For HUAWEI MA5608T

Description
Product Name: HUAWEI GPON SFP Bit Rate(Gb/s): TX2.5Gbps/RX1.25Gbps
Wavelength: 1490nm-TX/1310nm-RX Class: C+
Application: HUAWEI GPON System Keyword: HUAWEI MA5608T,HUAWEI GPON SFP
High Light:

HUAWEI MA5608T TX1490nm GPON OLT C+

,

FCC RX1310nm GPON OLT C+

,

2.5Gbps HUAWEI MA5608T GPON SFP Transceiver

TX1490nm/RX1310nm GPON OLT C+ SFP Transceiver for HUAWEI MA5608T


Description Of GPON OLT C+ SFP Transceiver for HUAWEI MA5608T

This 3rd HUWWEI GPON SFP is an optical gigabit module usually used in the HUAWEI GPON system, it can fully support the GPON OLT C+ application specified by the ITU-T G.984.2 Class C+ specifications.
This HUAWEI GPON SFP is programmed and tested to be fully compatible with a wide range of HUAWEI GPON OLT host devices such as HUAWEI MA5608T. it’s 100% equivalent to the original HUAWEI GPON SFP transceiver in function.

Specification Of GPON OLT C+ SFP Transceiver for HUAWEI MA5608T



Product Name HUAWEI GPON SFP For host device HUAWEI MA5608T
Compatible Brand HUAWEI Compatible P/N 34060694
Connector SC/UPC Maxim Link 20km
Data Rate (TX) 2.5Gbps RX Data Rate 1.25Gbps
Center Wavelength 1490nm RX Wavelength 1310nm
Power Consumption <1.5W Total Current 450mA
Transmitter Type DFB Receiver Type APD
TX Power +3 to +7dBm RX Sensitivity <-30dBm
Extinction Ratio >8.2dB RX Overload >-12dBm
Protocols SFF-8472, ITUT-984.2


Features Of GPON OLT C+ SFP Transceiver for HUAWEI MA5608T

  • Functionally identical to HUAWEI GPON SFP 34060694
  • Used on HUAWEI GPON system for example HUAWEI MA5608T
  • Single fiber bi-directional data links asymmetric TX 2488Mbps/RX1244Mbps application
  • 1490nm continuous-mode DFB laser transmitter and 1310nm burst-mode APD-TIA receiver
  • Hot-pluggable SFP package
  • SC/UPC Connector
  • Single 3.3V power supply
  • DDMI function available with internally calibrated mode
  • Digital burst RSSI function to monitor the input optical power level
  • LVPECL compatible data input/output interface
  • LVTTL transmitter disable control
  • LVTTL transmitter laser fault alarm
  • Fast LVTTL receiver Signal Detect (SD) indication response
  • Low EMI and excellent ESD protection
  • International Class1 laser safety certified
  • Operating temperature range:Commercial: -5°C~70°C  / Industrial: -40°C~85°C
  • RoHS6 Compliance


Application Of GPON OLT C+ SFP Transceiver for HUAWEI MA5608T

  • HUAWEI Gigabit-capable Passive Optical Networks (GPON)



FAQ



Q: Are you trading company or manufacturer?

We are original manufacturer. We can do OEM/ODM business. Our company mainly produces SFP Transceiver.



Q: What are your main products?

PON, SFP, SFP+, SFP28, QSFP+, QSFP28, CFP/CFP2/CFP4, FC, Video SFP, 1x9, XFP, x2, Xenpak, SFF optical transceiver series, as well as Active Optical Cable, Direct Attach Cable, OSA and so on. etc.



Q: Why choose GigaOpto?

1. Prompt delivery and remarkable services
2. Competitive selling prices
3. Rich experience in OEM & ODM co-operation
4. 100% new materials for production and 100% reliable quality



Q: How can you guarantee the quality of the GPON OLT C+ SFP Transceiver for HUAWEI MA5608T?

GigaOpto has rich experience in providing trusted quality service to customers, with a perfect quality management system, all of our products were 100% tested before shipment.



Q: What about the warranty of this GPON OLT C+ SFP Transceiver for HUAWEI MA5608T?

3-year warranty for new products, and lifetime technical support.



Q: Can I have a sample order? What is your MOQ for this GPON OLT C+ SFP Transceiver for HUAWEI MA5608T?

Yes, a sample order is available for your testing and checking quality. Mixed samples are acceptable, our MOQ is just one piece.



Q: Could I use our own logo, label and package?
Yes, we can help you to market your own brand of 3rd party transceivers
OEM customization : Your LOGO (Labeling); Your P/N (Labeling);Your S/N (Labeling);

EEPROM information: Vendor name: customized your information; P/N: customized your information; S/N: customized your information.



Q: What are your payment terms?

We accept T/T, Western Union, Paypal, L/C, etc.  For samples: 100% payment. Formal order: 30%as deposit, 70% balance payment before shipment. Gigaopto may be able to agree to more flexible terms with regular customers or customers with special large orders or products.



Q: How do you ship the GPON OLT C+ SFP Transceiver for HUAWEI MA5608T and how long does it take to arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
