OLT Asymmetric EPON XFP Module 1.25G SM 20km 1310nm PRX30 XFP T1577nm 10.3G T1490nm 1.25G

Asymmetrical 10GEPON OLT XFP PRX30 TX:1577nm(10.3125G)/TX:1490nm(1.25G)/RX1310nm(1.25G) SC/UPC 20km Transceiver Module

Description

The GIGAOPTO's GTX-SETB1-20DC optical transceiver module enables 10G Ethernet bi-directional communications, supporting various high-bandwidth EPON products. Conforming to the 10Gbps Small Form Factor Pluggable Multi-Source Agreement, this optical transceiver is designed expressly for high-speed bi-directional communication applications that require 10Gbps data rates. The transceiver complies with the IEEE 802.3av specification, utilizing a single fiber with a standard SC/UPC connector. The module could implement DDM function. It could be used at key locations in optical networks.

Specification

Features

• Single fiber bi-directional data links
• XFP package with SC/UPC Receptacle connector
• 3.3V, 5V power supply
• Hot-pluggable capability
• Support 20km transmission distance with SMF
• 10.3125Gbps 1577nm EML Continuous Mode TX
• 1.25Gbps 1490nm DFB Continuous Mode TX
• 1.25Gbps 1310nm APD Burst Mode RX
• Low EMI and excellent ESD protection
• Digital diagnostic monitor interface
• Low power consumption
• International Class 1 laser safety certified
• Operating case temperature: 0°C~70°C
• RoHS6 Compliance

Application

• Asymmetric 10GEPON OLT

Ordering Information

Compatibility

All of Gigaopto's optical modules are open-source and can be coded to be fully compatible with many highly popular optical devices. For this product (10GEPON OLT PRX30 XFP Asym (10G)T1577nm /(1G)T1490nm /(1G)R1310nm) please refer to the following compatibility table. If you would like more information about compatibility, please feel free to contact us.
