SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR

Certification
China Shenzhen Gigaopto Technology Co., Ltd. certification
China Shenzhen Gigaopto Technology Co., Ltd. certification
I'm Online Chat Now

SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR

SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR
SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR

Large Image :  SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Generic
Certification: CE, FCC, ROHS, ISO9001, ISO14000, MSDS, REACH, CP65, TUV, UL
Model Number: EX-SFP-10GE-SR
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: negotiable
Packaging Details: Static bag, Plastic bag, Retail box or by required
Delivery Time: 1-5 work days
Payment Terms: T/T, L/C
Supply Ability: 50,000pcs/month

SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR

Description
Features: SFP 850nm Product Name: Juniper Compatible SFP
Link: 300m On OM3, 400m On OM4 Connector: Duplex LC
Applications: Ethernet,10GFC Keywords: Sfp 850nm, EX-SFP-10GE-SR
High Light:

SFP 850nm MMF Transceiver Module

,

300m OM3 LC MMF Transceiver Module

,

EX-SFP-10GE-SR Transceiver Module

SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR





Description Of SFP 850nm



This SFP 850nm is an optical transceiver that uses an 850nm wavelength laser to transmit data at a rate of 10Gbps over a multi-mode fiber optic cable, maximum links up to 400m over OM4 MMF (300m over OM3 MMF) via an LC duplex connector.



This SFP 850nm is compliant with SFF-8431, SFF-8432, IEEE 802.3-2012 10GBASE-SR/SW and 10G Fibre Channel.Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472.



This SFP 850nm is commonly used in short-range applications, such as within a data center or between adjacent buildings.



This SFP 850nm optical transceiver is factory pre-programmed with all the necessary configuration data for seamless network integration and perform identically to genuine Juniper EX-SFP-10GE-SR transceivers, with excellent interoperation on Juniper network equipment.



Specification Of SFP 850nm



Compatible Brand Juniper Network
Compatible P/N EX-SFP-10GE-SR
Type SFP 850nm
Data Rate 10Gbps
Center Wavelength (nm) 850nm
Max Reach 300m OM3 or 400m OM4
Fiber Type Multimode Fiber
Connector LC Duplex
Optical Component VCSEL,PIN
Transmitt Power (dBm) -6~-1dBm
Receive Sensitivity < -10dBm
Extinction Ratio >3.5dB
Rx Overload >0.5dBm
DDM/DOM Support (default)
Unit Weight 25 gram



Features Of SFP 850nm



  • Hot-pluggable SFP 850nm transceiver
  • Functionally identical to Juniper EX-SFP-10GE-SR
  • 10.3Gbps bit rates
  • 400m on OM4 or 300m on OM3
  • Uncooled 850nm VCSEL laser
  • Receiver limiting electrical interface
  • Power dissipation < 1.0W
  • Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle v
  • Real-Time Digital Diagnostic Monitoring
  • Operating temperature range:Commercial: -5°C~70°C;Industrial: -40°C~85°C
  • RoHS compliant(lead-free)



Application Of SFP 850nm



  • 10GBASE-SR
  • 10GBASE-SW
  • Fiber Channel
  • Other Optical links



Package Outline Of SFP 850nm Transceiver

Dimensions are in millimeters. All dimensions are ±0.1mm unless otherwise specified. (Unit: mm)

SFP 850nm MMF Transceiver Module 300m OM3 LC For Juniper EX-SFP-10GE-SR 0



FAQ



Q: Are you trading company or manufacturer ?

We are an original manufacturer. We can do OEM/ODM business. Our company mainly produces SFP Transceiver.



Q: What are your main products?

PON, SFP, SFP+, SFP28, QSFP+, QSFP28, CFP/CFP2/CFP4, FC, Video SFP, 1x9, XFP, x2, Xenpak, SFF optical transceiver series, as well as Active Optical Cable, Direct Attach Cable, OSA and so on. etc.



Q: Why choose GigaOpto?

1. Prompt delivery and remarkable services
2. Competitive selling prices
3. Rich experience in OEM & ODM co-operation
4. 100% new materials for production and 100% reliable quality



Q: How can you guarantee the quality?

GigaOpto has rich experience in providing trusted quality service to customers, with a perfect quality management system, all of our products were 100% tested before shipment.



Q: What about the warranty of the SFP 850nm Transceiver?

3-year warranty for new products, and lifetime technical support.



Q: Can I have a sample order of SFP 850nm Transceiver? What is your MOQ of the SFP 850nm Transceiver?

Yes, a sample order is available for your testing and checking quality. Mixed samples are acceptable, our MOQ is just one piece.



Q: Could I use our own logo, label, and package on this SFP 850nm Transceiver?
Yes, we can help you to market your own brand of 3rd party transceivers
OEM customization : Your LOGO (Labeling); Your P/N (Labeling);Your S/N (Labeling);

EEPROM information: Vendor name: customized your information; P/N: customized your information; S/N: customized your information.



Q: What are your payment terms for the SFP 850nm Transceiver?

We accept T/T, Western Union, Paypal, L/C, etc. For samples: 100% payment. Formal order: 30% as deposit, 70% balance payment before shipment. Gigaopto may be able to agree to more flexible terms with regular customers or customers with special large orders or products.



Q: How do you ship the SFP 850nm Transceiver and how long does it take to arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
