Product Details:
|
| Product Name: | HP Compatible SFP Transceiver | Wavelength: | TX1270nm/RX1330nm |
|---|---|---|---|
| Max Distance: | 40km | Power Budget: | 16dB |
| Application: | 10 GbE,Data Center | Keywords: | J9151A-BX-40, HP Compatible SFP Transceiver |
| Highlight: | RX1330nm HP SFP Transceiver,J9151A-BX-40 Compatible HP SFP Transceiver,40km LC HP SFP Module |
||
TX1270nm RX1330nm HP J9151A-BX-40 Compatible SFP Transceiver 40km LC
Description Of HP Aruba J9151A-BX-40 Compatible SFP Transceiver
This HP Aruba J9151A-BX-40 compatible SFP transceiver module is designed for long reach 10Gb/s duplex optical data communications application such as 10GBASE-ER/EW defined by IEEE 802.3ae. It is with the SFP+ 20-pin connector to allow hotplug capability.
This HP Aruba J9151A-BX-40 compatible SFP transceiver module is compliant with SFF-8431,SFF-8432 standard. Digital diagnostic functions are available via an I2C interface, as specified in SFF-8472.
This module is programmed to works with a wide range of HP equipment such as 10 Gigabit Ethernet (10 GbE) Switches, Routers, Network Interface Cards (NICs) and Media Converters, which makes it be an ideal replacement to high-cost original HP Aruba transceiver.
Specification Of HP Aruba J9151A-BX-40 Compatible SFP Transceiver
| Compatible Brand | HP Aruba |
| Part Number | J9151A-BX-40 |
| Package Type | SFP+ BiDi ER |
| Data Rate | 10.3125Gb/s |
| Max Fiber Link | 40km |
| Connector | Single LC |
| Fiber Type | SMF |
| Power Budget | 16 dB |
| Operating Temp. | 0 to 70°C (32 to 158°F) |
| Wavelength (TX/RX) | 1270nm/1330nm |
| LD Component | DFB BiDi BOSA |
| TX Output Power | 1~6dBm |
| RX Sensitivity | <-15dBm |
| Extinction Ratio | >3.5dB |
| Receiver Saturation | >0.5dBm |
| Power Dissipation | ≤1.5W |
| DDMI | Support as default |
| Protocols | SFP+ MSA Compliant, CPRI, eCPRI |
Notice: When the long reach transceiver is used in short distance transmission, please matched with appropriate attenuator according to the table.
| Distance | ≤ 5km | ≤ 10km | ≤ 15km |
| Attenuator | 7dB | 5dB | 3dB |
Features Of HP Aruba J9151A-BX-40 Compatible SFP Transceiver
Application Of HP Aruba J9151A-BX-40 Compatible SFP Transceiver
FAQ
Q: Are you factory or trading company ?
Shenzhen GigaOpto Technology Co., Ltd is a specialized manufacturer of optical transceivers from 155Mbps to 100Gbps, covering PON, SFP, SFP+, SFP28, QSFP+, QSFP28, CFP/CFP2/CFP4, FC, Video SFP, 1x9,XFP, x2, Xenpak, SFF optical transceiver series, as well as Active Optical Cable, Direct Attach Cable, OSA and so on. etc.
Q: Can I have a sample order? What is your MOQ of this HP Aruba J9151A-BX-40 Compatible SFP Transceiver?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable,We do not have MOQ,1 sample is available.
Q: Are your transceivers compatible ?
Yes,our compatible optical module all test for compatibility on a variety of different brands of network equipment such as Cisco, Juniper, HP , Huawei, Alcatel-Lucent, H3C and more.
Q: How can you guarantee the quality ?
GigaOpto has rich experience in providing trusted quality service to customers, with perfect quality management system, all of our products were 100% tested before the shipment.
Q: What is operating temperature range of HP Aruba J9151A-BX-40 Compatible SFP Transceiver?
Commercial temperature range(Com.) : 0 to 70℃
Extended temperature range(Ext.):-20 to 85℃
Industrial temperature range(Ind.):-40 to 85℃
Q: Can you accept OEM/ODM order ?
Yes, please send inquiry to us so that we can have a detailed discussion.
Q: What is the lead time of HP Aruba J9151A-BX-40 Compatible SFP Transceiver?
For usual products,We keep stock,could ship about 3 days after received payment.For big quantity and special products,Please check lead time with our sales representative.
Q: What is your after-sales service of HP Aruba J9151A-BX-40 Compatible SFP Transceiver ?
All our customers can get three years quality warranty, and lifetime technical support.
