Product Details:
|
| Features: | 850nm MMF 100m | Product Name: | Cisco QSFP28 Transceiver |
|---|---|---|---|
| Connector: | MTP/MPO | Temperature: | -40 To 85°C (-40 To 185°F) |
| Application: | Data Center, HPC | Keywords: | QSFP-100G-SR4-I, 100G SR4 |
| Highlight: | MMF 100m Optical Transceiver Module,850nm MMF CISCO Compatible Transceivers,QSFP-100G-SR4-I Industrial CISCO Compatible Transceivers |
||
Cisco QSFP-100G-SR4-I Compatible QSFP28 MMF 100m Transceiver Module MPO DOM Industrial
Description Of Cisco QSFP-100G-SR4-I Compatible 100G SR4
This Cisco QSFP-100G-SR4-I Compatible four independent transmit and receive lanes transceiver module is designed for 100Gigabit Ethernet over Multi-Mode fiber with 70m using OM3 fiber or 100m using OM4 fiber with an MTP/MPO connector.
It is compliant with SFF-8665, SFF-8636 and IEEE 802.3bm standard.
Featuring an operating temperature range of -40°C to 85°C, this industrial fiber optic transceiver is capable to work in harsh industrial environments.
This 100G SR4 optical transceiver is factory pre-programmed with all the necessary configuration data for seamless network integration and performs identically to genuine Cisco QSFP-100G-SR4-I transceivers, with excellent interoperation with Cisco QSFP28 port optical transport devices.
Specification Of Cisco QSFP-100G-SR4-I Compatible 100G SR4
| Compatible Brand | Cisco | Compatible P/N | QSFP-100G-SR4-I |
| Packaging | QSFP28 | Bit Rate (Gbps) | 103.125Gbps (4x 25.78Gbps) |
| Wavelength | 850nm | Transmission | 70M OM3 / 100M OM4 |
| Connector | MTP/MPO-12 PC | Fibre Type | Multi-mode fiber |
| Transmitter Type | VCSEL | Receiver Type | PIN |
| TX Output Power | -8.4~2.4dBm | Rx Sensitivity | <-10.3dBm |
| Extinction Ratio | ＞2 dB | Rx Overload | >2.4dBm |
| Power budget (dB) | 1.9dB | Power Dissipation | ≤1.8W |
| DDM/DOM | Support as default | Operating Temperature | -40 to 85°C (-40 to 185°F) |
| CDR | TX & RX Built-in CDR | FEC Function | Supported |
| OEM/ODM | Supported | Modulation Format | NRZ |
| Protocols | IEEE 802.3bm, QSFP28 MSA, SFF-8665, SFF-8636, RoHS, CPRI, eCPRI | ||
Features Of Cisco QSFP-100G-SR4-I Compatible 100G SR4
Applications Of Cisco QSFP-100G-SR4-I Compatible 100G SR4
Standard Of Cisco QSFP-100G-SR4-I Compatible 100G SR4
FAQ
Q: Why choose us?
GigaOpto is the leading global supplier of optical transceivers and we have around 10 years of experience in this field. Our advantage.
Q: Are your transceivers compatible?
Yes, our compatible optical modules all test for compatibility on a variety of different brands of network equipment such as Cisco, Juniper, Arista, HP, Huawei, Alcatel-Lucent Nokia, H3C and more.
Q: Can I have a sample order Of Cisco QSFP-100G-SR4-I Compatible 100G SR4? What is your MOQ Of Cisco QSFP-100G-SR4-I Compatible 100G SR4?
Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable, We do not have MOQ,1 sample is available.
Q: What are your payment terms for Cisco QSFP-100G-SR4-I Compatible 100G SR4?
Usually, we need prepayment by T/T, West Union, or Paypal.
Could also support L/C, Credit terms.
Q: Could I return the Cisco QSFP-100G-SR4-I Compatible 100G SR4 if there is a quality problem?
Yes, if there is a quality problem happen, we could accept a free exchange.
Q: Could I use our own logo and label on the Cisco QSFP-100G-SR4-I Compatible 100G SR4?
Yes, we could provide an OEM service and make the products with your own label.
