1000BASE-BX Cisco SFP BiDi Transceiver TX1490nm / RX1310nm SMF 10km For GLC-BX-D

1000BASE-BX Cisco SFP BiDi Transceiver TX1490nm / RX1310nm SMF 10km For GLC-BX-D
1000BASE-BX Cisco SFP BiDi Transceiver TX1490nm / RX1310nm SMF 10km For GLC-BX-D 1000BASE-BX Cisco SFP BiDi Transceiver TX1490nm / RX1310nm SMF 10km For GLC-BX-D 1000BASE-BX Cisco SFP BiDi Transceiver TX1490nm / RX1310nm SMF 10km For GLC-BX-D

Large Image :  1000BASE-BX Cisco SFP BiDi Transceiver TX1490nm / RX1310nm SMF 10km For GLC-BX-D

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Gigaopto
Certification: CE, FCC, ROHS, ISO9001, ISO14000, MSDS, REACH, CP65, TUV, UL
Model Number: GLC-BX-D
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiable
Packaging Details: Static bag, Plastic bag, Retail box or by required
Delivery Time: 1-5 work days
Payment Terms: T/T, L/C
Supply Ability: 50,000pcs/month

1000BASE-BX Cisco SFP BiDi Transceiver TX1490nm / RX1310nm SMF 10km For GLC-BX-D

Description
Product Name: Cisco SFP Transceiver Bit Rate: 1250Mb/s
Cable Distance: 10km Wavelength: T1490nm/R1310nm
Application: Gigabit Ethernet/1G Fiber Channel Keywords: Cisco 1000BASE-BX, GLC-BX-D
Highlight:

1000BASE-BX SFP BiDi Transceiver

,

SMF SFP BiDi Transceiver

,

GLC-BX-D CISCO Compatible Transceivers

Cisco GLC-BX-D Compatible 1.25Gbps BiDi SFP Transceiver Module 1490nm-TX/1310nm-RX 10km SMF DOM Simplex LC





Description Of Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver



This Cisco GLC-BX-D compatible 1000BASE-BX transceiver is a hot-pluggable SFP bi-directional (BiDi) transceiver module specifically for duplex optical data communications such as 1000BASE-BX Gigabit Ethernet per IEEE802.3z and 1G Fibre Channel application. This bi-directional unit must be used with another transceiver or network equipment of complementary wavelengths.



This bi-directional SFP transceiver is 100% functionally identically to OEM Cisco GLC-BX-D transceiver, which can work with a wide variety of Cisco networking equipment such as Cisco 2800 NME-XD-24ES-1S-P, Cisco 2900 EHWIC-1GE-SFP-CU, Cisco 3000 WS-CBS3040-FSC, Cisco 3845, Cisco 3900 SM-D-ES3G-48-P, Cisco 4500 WS-X4516-10GE, Cisco 5700 WLC AIR-CT5760-1K-K9, Cisco 7600 7600-ES20-GE3CXL, Cisco A901-4C-F-D, Cisco IE-2000-4S-TS-G-L, etc.



Specification Of Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver



Compatible Brand Cisco Compatible P/N GLC-BX-D
Form Type BIDI SFP Data Transfer Rate 1.25Gbps
Optical Receptacle Type Single LC Max Cable Distance 10km
DOM/DDM Supported Yes Fibre Mode Single-mode
Typical Wavelength Tx1490nm/Rx1310nm Temperature 0 to 70°C (32 to 158°F)
Power Consumption <1W Icc <300mA
LD Type DFB Photo-detector PIN
TX Optical Power -9~-3dBm Sensitivity < -22dBm
Extinction Ratio >9dB Receiver Overload >-3dBm
Protocols IEC/EN 61000-4-2,IEC-60825, FDA 21CFR 1040.10 and 1040.11



Features Of Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver



  • Hot-pluggable Cisco BIDI SFP Transceiver
  • Functionally equivalent to Cisco GLC-BX-D
  • 1.25 Gbit/sec line speed.
  • Operating distance up to 10km over single-mode fiber
  • Transmitter wavelength 1310nm/RX 1490nm
  • Industry-standard Simplex LC connector
  • +3.3V single power supply
  • Low power dissipation
  • Compliant with SFP MSA
  • Compliant with SFF-8472
  • Compliant with RoHS6



Application Of Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver



  • 1G Fibre Channel
  • Gigabit Ethernet



FAQ



Q: Why choose us?

GigaOpto is the leading global supplier of optical transceivers and we have around 10 years of experience in this field. Our advantage.

  • Competitive prices.
  • High quality products and services.
  • Fully compatible (Cisco/Juniper/HP/Huawei/Alcatel-Lucent Nokia/H3C...)
  • Big capability of manufacture for 40K~100K pcs per month.
  • Independent R&D ability.
  • Keep stock, Fast delivery



Q: Are your transceivers compatible?
Yes, our compatible optical modules all test for compatibility on a variety of different brands of network equipment such as Cisco, Juniper, Arista, HP, Huawei, Alcatel-Lucent Nokia, H3C and more.



Q: Can I have a sample order of Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver? What is your MOQ of the Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver?

Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable, We do not have MOQ,1 sample is available.



Q: What are your payment terms for this Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver?
Usually, we need prepayment by T/T, West Union or Paypal.

Could also support L/C, Credit terms.



Q: Could I return the Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver if there is a quality problem?
Yes, if there is a quality problem happen, we could accept a free exchange.



Q: Could I use our own logo and label on this Cisco GLC-BX-D Compatible 1000BASE-BX Transceiver?

Yes, we could provide an OEM service and make the products with your own label.
