Product Details:
|
| Form Factor: | SFP+ | Wavelength: | 850mn |
|---|---|---|---|
| Distance: | 300mm | Data Rate: | 10.3125Gbps |
| Operating Temperature: | 0~70℃ | Connector: | Duplex LC |
10GBASE-SR SFP+ 850nm 300m Duplex LC MMF DOM Optical Transceiver Module
Product Description
Gigaopto's GTS-L0896-02Mx SFP+ transceiver supports up to 400m link lengths over OM4 MMF (300m over OM3 MMF) via an LC duplex connector. This 10G SFP+ transceiver is ideal for data centers, enterprise wiring closets, service provider transport applications, Radio & Baseband Units, etc.
Features
Applicatiions
Specifications
| Transmitter Type | VCSEL | Receiver Type | PIN |
| TX Power | -7.3~-1dBm | Receiver Sensitivity | < -11.1dBm |
| Powerbudget | 3.8dB | Receiver Overload | 0.5dBm |
| Power Consumption | ≤0.6W | Extinction Ratio | >3dB |
| Power Supply | DDM/DOM | Supported |
| Part No. | Package | Data Rate(Gbps) | Wavelength(nm) | Class | Connector | Temp. | Datasheet |
| GTS-SET11-20DxB | SFP | Tx1.25/Rx1.25 | Tx1490/Rx1310 | PX20+ | SC | 0~+70; -40~+85 | |
| GTS-SET11-20DxC | SFP | Tx1.25/Rx1.25 | Tx1490/Rx1310 | PX20++ | SC | 0~+70; -40~+85 | |
| GTS-SET11-20DxD | SFP | Tx1.25/Rx1.25 | Tx1490/Rx1310 | PX20+++ | SC | 0~+70; -40~+85 |
